1. What is Incoloy 825?

Incoloy 825 is a high-performance nickel-iron-chromium alloy with excellent corrosion resistance to oxidizing acids (such as nitric acid), reducing acids (such as sulfuric acid and phosphoric acid), chloride environments, and sulfide environments. Its mechanical properties remain stable over a temperature range of room temperature to 550°C.

2. Advantages of Freeman Valve's Incoloy 825 API 602 globe valve:

2.1 Freeman Valve's Incoloy 825 API 602 globe valve exhibit excellent corrosion resistance to oxidizing acids (such as nitric acid) and reducing acids (such as sulfuric acid and phosphoric acid), especially performing exceptionally well under medium-concentration sulfuric acid and phosphoric acid conditions at low and medium temperatures;

2.2 Freeman Valve's Incoloy 825 API 602 globe valve possess strong resistance to chloride corrosion, effectively resisting pitting corrosion, crevice corrosion, and stress corrosion cracking (SCC), making them suitable for chlorinated seawater, brine, and chemical media environments;

2.3 Freeman Valve's Incoloy 825 API 602 globe valve is resistant to sulfide corrosion and can be used in acidic oil and gas wells in the oil and gas industry, resisting sulfide stress cracking (SSC);

2.4 Freeman Valve's Incoloy 825 API 602 globe valve maintain stable strength and ductility within a temperature range of room temperature to 550°C, and also possess good toughness at low temperatures, without low-temperature brittleness;

2.5 Freeman Valve's Incoloy 825 API 602 globe valve has excellent weldability;

2.6 Freeman Valve's Incoloy 825 API 602 globe valve effectively prevent intergranular corrosion due to the addition of titanium, which combines with carbon to form carbides, preventing the precipitation of chromium carbides at grain boundaries. This makes them particularly suitable for applications where post-weld solution treatment is not possible.

3. Classic Applications of Freeman Valve's Incoloy 825 API 602 globe valve:

3.1 Wet-Process Phosphoric Acid Production: Freeman Valve's Incoloy 825 API 602 globe valve is advantageous in wet-process phosphoric acid production due to their resistance to medium-low temperature, medium-concentration phosphoric acid corrosion, resistance to chloride/fluoride ion pitting and stress corrosion, and the elimination of post-treatment requirements for welded joints;

3.2 Phosphoric Acid-Based Fertilizer Production: Freeman Valve's Incoloy 825 API 602 globe valve is the preferred material for the production of ammonium phosphate (MAP/DAP);

3.3 Metal Pickling and Surface Treatment: Freeman Valve's Incoloy 825 API 602 globe valve is crucial control units in sulfuric acid pickling lines, capable of withstanding accumulated metal ions (Fe²⁺/Fe³⁺) and chlorides in the acid solution;

3.4 Hydrometallurgy: Freeman Valve's Incoloy 825 API 602 globe valve can handle complex acidic solutions in the leaching, extraction, and electrowinning processes of copper, zinc, cobalt, and nickel;

3.5 Waste Acid Regeneration: Freeman Valve's Incoloy 825 API 602 globe valve has been widely used in process equipment for recovering sulfuric acid from waste acid.

Design Standard of Incoloy 825 Globe Valve:

Design Acc. to ASME B16.34 (ANSI Standard Incoloy 825 Globe Valve);

Design Acc. to EN-12516-1/2 (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve).

Test Standard of Incoloy 825 Globe Valve:

Test Acc. to API 598 (ANSI Standard Incoloy 825 Globe Valve);

Test Acc. to EN 12266-1/2 (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve).

Surface Finishing of Incoloy 825 Globe Valve:

All Incoloy 825 Globe Valve surface is finely machined to achieve the required roughness and conforms to standard MSS SP-110.

Size of Incoloy 825 Globe Valve:

From DN1/4’’ to 48’’ (ANSI Standard Incoloy 825 Globe Valve);

From DN8 to DN1200 (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve).

Face to Face of Incoloy 825 Globe Valve:

Face to Face Acc. to ASME B16.10 (ANSI Standard Incoloy 825 Globe Valve);

Face to Face Acc. to EN 558-1 (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve).

Pressure Rating of Incoloy 825 Globe Valve:

ANSI Class 150 Incoloy 825 Globe Valve (ANSI Standard Incoloy 825 Globe Valve);

ANSI Class 300 Incoloy 825 Globe Valve (ANSI Standard Incoloy 825 Globe Valve);

ANSI Class 600 Incoloy 825 Globe Valve (ANSI Standard Incoloy 825 Globe Valve);

ANSI Class 800 Incoloy 825 Globe Valve (ANSI Standard Incoloy 825 Globe Valve);

ANSI Class 900 Incoloy 825 Globe Valve (ANSI Standard Incoloy 825 Globe Valve);

ANSI Class 1500 Incoloy 825 Globe Valve (ANSI Standard Incoloy 825 Globe Valve);

ANSI Class 2500 Incoloy 825 Globe Valve (ANSI Standard Incoloy 825 Globe Valve);

EN 1092 PN 16 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve);

EN 1092 PN 25 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve);

EN 1092 PN 40 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve);

EN 1092 PN 63 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve);

EN 1092 PN 100 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve);

EN 1092 PN 160 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve);

EN 1092 PN 250 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve);

EN 1092 PN 320 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve);

EN 1092 PN 400 Incoloy 825 Globe Valve (EN Standard Incoloy 825 Globe Valve, DIN Standard Incoloy 825 Globe Valve).

Working Temperature of Incoloy 825 Globe Valve:

Please refer to the "Temperature and Pressure Curve of Incoloy 825 Globe Valve" for temperature and pressure changes.

Ends Connection of Incoloy 825 Globe Valve:

ANSI Flange Ends Incoloy 825 Globe Valve;

ANSI Integral Flange Ends Incoloy 825 Globe Valve;

ANSI Welded Flange Ends Incoloy 825 Globe Valve;

Butt Weld (ASME B16.25) Ends Incoloy 825 Globe Valve;

Butt Weld x ANSI Flange Ends Incoloy 825 Globe Valve;

EN 1092 Flange Ends Incoloy 825 Globe Valve;

EN 1092 Integral Flange Ends Incoloy 825 Globe Valve;

EN 1092 Welded Flange Ends Incoloy 825 Globe Valve;

Butt Weld (EN 12627) Ends Incoloy 825 Globe Valve;

Butt Weld (ISO 1127) Ends Incoloy 825 Globe Valve;

Butt Weld x EN 1092 Flange Ends Incoloy 825 Globe Valve;

Male NPT (ASME B1.20.1) Ends Incoloy 825 Globe Valve;

Male BSPP (ISO 228-1) Ends Incoloy 825 Globe Valve;

Male BSPT (ISO 7-1) Ends Incoloy 825 Globe Valve;

Male NPT x Female NPT Ends Incoloy 825 Globe Valve;

Male BSPP x Female BSPP Ends Incoloy 825 Globe Valve;

Male BSPT x Female BSPT Ends Incoloy 825 Globe Valve;

Male NPT x Long Butt Weld (+100 mm) Ends Incoloy 825 Globe Valve;

Male BSPP x Long Butt Weld (+100 mm) Ends Incoloy 825 Globe Valve;

Male BSPT x Long Butt Weld (+100 mm) Ends Incoloy 825 Globe Valve;

Female NPT (ASME B1.20.1) Ends Incoloy 825 Globe Valve;

Female BSPP (ISO 228-1) Ends Incoloy 825 Globe Valve;

Female BSPT (ISO 7-1) Ends Incoloy 825 Globe Valve;

Socket Weld (ASME B16.11) Ends Incoloy 825 Globe Valve;

Socket Weld (EN 12760) Ends Incoloy 825 Globe Valve;

Female NPT x Socket Weld Ends Incoloy 825 Globe Valve;

Female BSPP x Socket Weld Ends Incoloy 825 Globe Valve;

Female BSPT x Socket Weld Ends Incoloy 825 Globe Valve;

Butt Weld (ASME B16.25) Ends Incoloy 825 Globe Valve;

Butt Weld (EN 12627) Ends Incoloy 825 Globe Valve;

Female NPT x Butt Weld Ends Incoloy 825 Globe Valve;

Female BSPP x Butt Weld Ends Incoloy 825 Globe Valve;

Female BSPT x Butt Weld Ends Incoloy 825 Globe Valve;

Female NPT x Long Butt Weld (+100 mm) Ends Incoloy 825 Globe Valve;

Female BSPP x Long Butt Weld (+100 mm) Ends Incoloy 825 Globe Valve;

Female BSPT x Long Butt Weld (+100 mm) Ends Incoloy 825 Globe Valve;

Long Butt Weld (+100 mm Weld Stub) Ends Incoloy 825 Globe Valve.

CE Marking of Incoloy 825 Globe Valve:

CE Marking is Available to Incoloy 825 Globe Valve with a Diameter of DN32 or Larger.

Chemical Composition of Incoloy 825 Globe Valve:

For the Chemical Composition of Incoloy 825 Globe Valve, please refer to EN 10204 Type 3.1 certificate.

Mechanical Properties of Incoloy 825 Globe Valve:

For the Mechanical Properties of Incoloy 825 Globe Valve, please refer to EN 10204 Type 3.1 certificate.

Certificate of Incoloy 825 Globe Valve:

All Incoloy 825 Globe Valve will be delivered with EN 10204 Type 3.1 Certificate.

Approvals of Incoloy 825 Globe Valve:

MSS SP-110 Certified of Incoloy 825 Globe Valve;

NACE MR 0175 Certified of Incoloy 825 Globe Valve

API 607 Fire Safe Certified of Incoloy 825 Globe Valve;

ISO 9001 Certified of Incoloy 825 Globe Valve;

PED Certified of Incoloy 825 Globe Valve.

Available Upon Request of Incoloy 825 Globe Valve:

NACE MR0175 is available upon request of Incoloy 825 Globe Valve;

ATEX is available upon request of Incoloy 825 Globe Valve;

TA-LUFT is available upon request of Incoloy 825 Globe Valve;

SIL is available upon request of Incoloy 825 Globe Valve;

Degreasing is available upon request of Incoloy 825 Globe Valve;

Fire Safe is available upon request of Incoloy 825 Globe Valve;

Stem Extension is available upon request of Incoloy 825 Globe Valve;

Double Block and Bleed is available upon request of Incoloy 825 Globe Valve.
