Sturdy VFLO Characterised V-notch ball valve is available in sizes 2 through 14 inch ANSI Classes 150, 300 and 600 and in all castable materials. It is designed to overcome the problems of particle entrained processes. VFLO solves many long standing problems faced by traditional ball valves, such as:

Inadequate shutoff capabilities.

Piping forces that unevenly load the seat.

Low rangeability due to limited orifice characterisations.

VFLO reduces torque loads that adversely affect sealing and exceeds 300 to 1 rangeability with strong shearing capacity. VFLO achieves Class IV shutoff with a metal seal and Class VI shutoff with a soft seal. Many important features and options which VFLO uses to fulfill these and other requirements for ruggedness and high performance are listed below.

V-Port Regulating Ball Valve 2 PC Body ANSI Class 150 Class 300 PN16 PN40

Series 14 Model 51 SERIES 90DV SERIES 90V Flanged Ball Valves V-Port Regulating Ball Valves 2-piece Fire safe Flanged Ball Valve ANSI Class 150 Class 300 PN16 PN40 JIS 10K JIS 20K Full port Face to face ANSI B16.10 EN 558-1 DIN 3202-F1 DIN 3202-F4 DIN 3202-F5 API 607 Body CF8M WCB Special Alloy based on request Seats PTFE RTFE standard or other options based on request Available in Double body gasket design Available with 30 degree 60 degree 90 degree V-port ball for flow control Optional NACE MR0175 based on request

 V-Control Ball Valve

Series 14 Model 51 Control Ball Valve V-Control Body Materials Stainless Steel CF8M Carbon Steel WCB Stem Materials Tek-Fil PEEK Metal Maximum Allowable Operating Pressure ASME Class 150 ASME Class 300 ASME Class 600 EN 1092 PN10 EN 1092 PN 16 EN 1092 PN 25 EN 1092 PN 40 Seat Materials Standard Tek-Fil PEEK RPTFE TFM Metal Shutoff Rating Class VI Ball Materials 316 Stainless Steel CF8M Body Style Threaded Socket Weld Butt Weld Flanged End Design Standard ASME B16.34 15 Degree V-Port 30 Degree V-Port 60 Degree V-Port 90 Degree V-Port Custom Slotted Port Custom V-Port Face to Face ASME B16.10
